Antec VP450

http://store.antec.com/vpseries/vp450.html

BACK

• Technical Specifications
  Model	VP450
  Series	VP Series
  Part Number	0-761345-23540-2
  Type	Power Supply
  Compliant with	ATX12V 2.3 & EPS12V 2.92
  Efficiency	≤ 80%
  Wattage	450W

  Output
  	+3.3V	+5V	+12V1	+12V2	-12V	+5Vsb
  MAX	24A	15A	18A	18A	0.3A	2.5A
  TOTAL	120W		360W		3.6W	12.5W
  	450W

  Static Characteristics
  	+3.3V	+5V	+12V1	+12V2	-12V	+5Vsb
  Regulation	±5%	±5%	±5%	±5%	±10%	±5%
  Ripple & Noise	≤50mV	≤50mV	≤120mV	≤120mV	≤120mV	≤50mV

  Other Specifications
  Input Voltage	110 - 120VAC / 220-240VAC ~
  Input Current	10A / 5A
  Input Frequency	50Hz - 60Hz
  Operating Temperature	0⁰C - 25⁰C
  MTBF	≥ 100,000 hours
  PROTECTIONS	Over Current Protection (OCP), Over Power Protection (OPP), Over Voltage Protection (OVP), Short Circuit Protection (SCP)
  Safety Certificates	cUL, FCC, CB, BSMI
  Origin	Made in China

  Dimensions & Weight
  Model	3.4" x 5.9" x 5.5" (HxWxD) / 86mm x 150mm x 140mm (HxWxD)
  Net Weight	3.3lbs / 1.5kg
  Unit Carton	8.3" x 9.1" x 4.3" (HxWxD) / 210mm x 230mm x 110mm (HxWxD)
  Gross Weight	4.2lbs / 1.9kg

Connectors:

1 X 20+4 pin

1 X 6 Pin PCI-E

4 X SATA

4 X Molex

1 X floppy

1 X 4+4 Pin ATX/EPS
